15.6 inch，Intel Celeron N5100 Windows Panel PC
SP15-J Product Overview
The SP15-J is a rugged, 15.6-inch Windows-based laptop designed for durability and performance in demanding environments. Key specifications include:
- Operating System: Windows 10 Pro (Windows 10 Home and Windows 11 Pro optional)
- CPU: Intel Celeron N5100 Quad-Core, up to 2.80GHz (turbo)
- GPU: UHD Graphics with 24 Execution Units (EUs)
- RAM/Storage:
- 8GB/256GB
- Optional: 4GB/64GB
- Display: 15.6-inch IPS LCD, 1080x1920 resolution
- Touchscreen: 10-point touch, stylus support
- WiFi: 802.11a/b/g/n/ac, dual-band (2.4G & 5G), Intel Dual Band Wireless-AC 7265 (WiFi/Bluetooth 2-in-1), optional external antenna
- Bluetooth: 4.2
- Speaker: 4Ω 2.0Watt x2
- Ports:
- HDMI x1, RJ45 x1, RS232 x1, Earphone x1, DC x2 (4.0x15mm), USB 3.0 x2
- Durability:
- IP65 dust and water resistance
- 1.2-meter drop resistance
- Temperature:
- Storage: -25°C to 80°C
- Operation: -20°C to 55°C
Accessories: Box, DC Charger (12V 4A)
The SP15-J combines a large display, rugged design, and versatile connectivity options, making it ideal for industries requiring a durable and reliable computing solution.
Specifications
| SP15-J SPEC | ||
| ITEM | DESCRIPTION | DETAIL |
| OS | Windows 10 Pro | Windows 10 Home Optional Windows 11 pro Optional |
| CPU | Intel Celeron N5100 (Quad Core, Quad Threads; 1.10GHz) | Turbo can reach 2.80GHz |
| GPU | UHD Graphics 24 EUs | |
| RAM/ROM | 8GB/256GB | 4GB/64GB Optional |
| LCD | 15.6 inch; 1080*1920 | IPS |
| Touch Screen | 10 Point Touch | Support stylus |
| WIFI | 802.11a/b/g/n/ac Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G | Module：Intel® Dual Band Wireless-AC 7265 (WIFI/Bluetooth 2-in-1) Antenna built-in or external Optional |
| BLUETOOTH | 4.2 Version | |
| SPEAKER | 4Ω 2.0 Watt *2 | |
| Size | 384*234*22.5mm | |
| Weight | 2600±50g (without antenna) | |
| Language | Multi language | |
| Interface In/Out Port | 1. HDMI*1 2. RJ45*1 3. RS232*1 4. Earphone*1 5. DC*2: 4.0*15mm 6. USB 3.0 *2 | |
| Button | V+ -, Power | |
| Accessories | 1. Box 2. DC Charger (12V 4A) | |
| Multi-Media (Hardware Decoding) | 1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) | |
| Proof Degree | Anti-dust & Waterproof IP65 Dropping Resistance 1.2 meters | |
| Temperature | Storate Temperature: -25 °C to 80 °C Operation Temperature: -20 °C to 55 °C |
Case
Download
SP15-J Data Download
Sincoole specializes in the design and production of rugged devices, with 10 years of industry experience. Our expertise lies in rugged tablets, handheld devices, and industrial computers, deeply rooted in various industries such as industrial applications, new energy applications, medical applications, outdoor data collection, chemical applications, aerospace, and military applications, empowering enterprises. We look forward to collaborating with you.
