Core Specifications & Performance

• Operating System:
  Runs on Android 13.0, providing a stable and up – to – date platform with access to the latest Android applications. This allows users to leverage a wide range of software for various tasks, from productivity apps to industry – specific tools.
• Processor:
  • Base model is powered by the Unisoc T616 (T7250) octa – core processor running at 1.8GHz. There’s an optional Unisoc T606 processor, giving users the flexibility to choose based on their performance requirements.
• Graphics:
  Features the Mali – G57 MP1 GPU clocked at 850MHz. It can handle graphical tasks such as video playback and basic graphical user interfaces smoothly, ensuring a decent visual experience for users.
• Memory/Storage:
  Comes with two configurations: 4GB/64GB and 8GB/128GB. The different options enable users to select the setup that best suits their multitasking and storage needs, whether they require more memory for running multiple apps simultaneously or additional storage for data – intensive tasks.

Display & Interaction

• Screen:
  The 10.1 – inch TFT screen has a resolution of 1200×1920. With a typical brightness of 350nits and a maximum of 400nits, it offers clear visuals in different lighting conditions. Whether used indoors or outdoors, users can expect to view content without much difficulty.
• Touch:
  Supports 10 – point touch and stylus input, enabling precise operation. This is beneficial for tasks like data entry, navigating through complex interfaces, and interacting with touch – based applications, even when wearing gloves or in less – than – ideal conditions.

Power & Mobility

• Battery:
  • Equipped with a 10000mAh (3.8Vdc, 38.0Wh) battery. It provides sufficient power for extended use in the field, allowing users to work continuously for a long time without frequent charging.
  • Although the charging time is not specified, it comes with a 5V 3A DC charger, which is a common and convenient charging solution.
• Design:
  Compact and lightweight, measuring 252.0×168.0×13.8mm and weighing 800±50g. Its portable design makes it easy to carry around during field operations, and the included accessories like a carry strap (if any) would further enhance its portability.

Connectivity & Expansion

• Wireless:
  • WWAN: Supports FDD – LTE, TDD – LTE, WCDMA, and GSM networks, covering a wide range of frequency bands. This ensures reliable mobile connectivity across different regions, allowing for seamless communication and data transfer on the go.
  • WiFi: 802.11a/b/g/n/ac wireless technology with 2.4G and 5G support, enabling high – speed wireless networking.
  • Bluetooth 5.0: Allows for seamless pairing with other devices, such as headphones, speakers, or external keyboards.
  • GPS: Incorporates BDS, GPS, and GLONASS, providing accurate positioning for applications like asset tracking, navigation, and location – based services.
  • NFC: 13.56 MHz (ISO/IEC 14443 A/B, ISO/IEC 15693) enables contactless data transfer and identification, which is useful for tasks like access control and payment processing.
• Wired Interfaces:
  Features 1×Type – C port, which is versatile and can be used for charging, data transfer, and connecting to external devices.

Durability & Certification

• Rugged Build:
  • IP65 – rated for dustproof and waterproof protection, and can withstand drops of up to 1.2 meters. This makes it suitable for use in harsh industrial environments, construction sites, warehouses, and outdoor settings.
  • Operating Temperature: -20°C to 55°C; Storage Temperature: -30°C to 60°C, ensuring reliable performance across a wide range of temperatures.
• Certifications:
  While not explicitly stated in the same way as some other models, its IP65 rating and ability to meet the temperature requirements imply a certain level of quality and durability standards.

Multimedia & Customization

• Cameras:
  • Front: 5MP camera for video conferencing and self – documentation.
  • Rear: 13MP camera, suitable for barcode scanning (with optional NLS – N1 scanner), inspection, and general photography.
• Audio:
  A speaker with dimensions 40×22.59×3.1mm and an impedance of 8Ω 1W, along with a microphone (-42db, 2.2kΩ), ensures clear audio for communication and media playback.
• Optional Features:
  • 1D/2D barcode scanner (NLS – N1 optional) can be added for specialized industrial applications, such as inventory management and logistics tracking.
  • Buttons like V + -, Power, and “SOS” (changed to “Scan” in the scanner version) offer basic functionality, and the tablet’s design allows for easy operation in different scenarios.

Accessories & Applications

• Included:
  Comes with a packaging box and a 5V 3A DC charger, providing the essential items for immediate use.
• Ideal For:
  Ideal for industries such as logistics, field service, and inventory management where cost – effectiveness, durability, and basic functionality are key requirements. Its Android – based system, rugged design, and connectivity options make it a reliable choice for these applications.
